Architectural Wire Mesh

A collection of architectural wire mesh samples by BZ Wire Mesh, showing diverse weaves including interlocking crimped and open diamond designs.

● Architectural Wire Mesh: The Fusion of Form & Function

A high-performance decorative material crafted from premium stainless steel, aluminum, copper, or bronze. It blends modern aesthetics with functional versatility for both interior and exterior design.

● Key Advantages

- Durability: Weather-resistant metals built for long-term use.

- Aesthetics: Diverse patterns with premium PVD or powder-coated finishes.

- Efficiency: Optimizes ventilation, light diffusion, and solar heat reduction.

- Safety: High-strength impact resistance for fall prevention.

- Versatility: Supports 3D sculptural forms and LED smart-tech integration.

- Mounting: Flexible fixed, sliding, or modular installation systems.

● Core Applications

- Exterior: Building facades, cladding, balconies, and terraces.

- Interior: Room dividers, decorative partitions, and ceilings.

- Safety: Railings, balustrades, and protective infills.

- Climate: Sunshades, windbreaks, and acoustic screens.

- Sustainability: Support structures for green

Here are some application cases for BZ's architectural mesh products:


Case: BZ-S009 (366 m²)	Case: BZ-1706C (72 m²)


Case: AL Expanded Metal (1240 m²)	Case: BZ-5130 (80m²)

Our Core Series:

BZ Wire Mesh specializes in three main categories tailored to architectural needs:

- Woven Wire Mesh Series --- Intricate patterns from round/flat wires.

- Expanded / Perforated Metal Series --- Lightweight, colorful panels for cladding and ceilings.

- Architectural Cable Mesh Series--- Tensioned rope + rod systems for modern facades.

View detailed specifications and examples:

Stainless Steel Cable Mesh

◆ Stainless Steel Cable Mesh By BZ Wire Mesh

☆Product Types of Stainless Steel Cable Mesh ☆The Material Used in Stainless Steel Cable Mesh ☆The Main Parameters of Stainless Steel Cable Mesh ☆Normal specifications of Stainless Steel Cable Mesh ☆The Applications of Stainless Steel Cable Mesh ☆BZ Wire Mesh Technique Supports ☆The Project BZ Wire Mesh Involved

Inter-Woven And Ferrule Type Stainless Steel Cable Mesh

● Stainless Steel Cable Mesh, also called Flexible Stainless Steel Cable Mesh, Stainless Steel Rope Mesh, Stainless Steel Wire Rope Mesh, it is produced of high quality stainless steel wire cable. It can be divided into ferrule type and inter-woven type by production crafts.

Due to the different styles of these two rope mesh products, we also refer to the ferrule type rope mesh as stainless steel ferrule mesh, X-TEND Mesh. The inter-woven type wire rope mesh is a pure hand-woven net, which is also called as interwoven stainless steel cable mesh, hand-woven wire rope mesh, or knotted stainless steel cable mesh.

● Stainless steel cable mesh is made from stainless steel wire rope in various material type like AISI 304 , AISI 316 , AISI 316L etc. The selected wire rope has two main strand structures:7*7 and 7*19. Generally, when the diameter of the steel wire rope is less than 2.5mm, the strand structure is 7*7, and when it is longer than 2.5mm, the strand structure is 7*19. The ferrule material is usually stainless steel, sometimes aluminum, copper, and other materials are used. In addition, we can also oxidize or spray the surface of the stainless steel cable mesh according to customer needs.

● Stainless steel cable mesh mainly has the following advantages:

1. High tensile strength with light weight.

2. Safe and environmental protection, close to nature.

3. Good resistance for weather and corrosion.

4. High transparency and good invisible effect.

5. Large mesh span for huge surface installation.

6. The structure is strong and durable, with a service life of more than 30 years

7. Various graphics and structures can be designed arbitrarily.

8. Easy to install, can be constructed on any structure.

● Stainless steel cable mesh is mainly used in the construction for wild zoos, large animal enclosure or aviaries, garden green walls, and also handrail infill or safety mesh. Stainless steel ferrule cable mesh and stainless steel inter-woven cable mesh have different characteristics and applications due to different weaving techniques. Compared with ferrule type rope mesh, the inter-woven type net is lighter in weight, more flexible, and has higher transparency, making it especially suitable for applications such as zoo mesh and fall protection netting. Ferrule type rope mesh is more aesthetically pleasing and decorative, and is often used as an architectural wire mesh for decorative and protective purposes in the construction field.

● BZ Wire Mesh plant which has been manufacturing the stainless steel mesh products since 1990, with stainless steel cable mesh being one of our specialty products. The plant's independent developed equipment's and skilled technique can ensure high quality products and sound service worldwide. In addition to providing products, we also provide design and installation technical support for our customers.

◆Product Types of Stainless Steel Rope Mesh

Rope mesh products are supplied in two main series according to different weave-types: Inter-woven(Knotted) and Ferrule Type. And according to the materials and ferrules we used, as well as weaving methods and different applications, wire rope mesh can be subdivided into many different styles and types of products. You can learn more about the different types of wire rope mesh through the links below.

◆The Material Used in Stainless Steel Rope Mesh

The main material of ss cable mesh are ss cable and various of ferrules. The cable is made from high quality stainless steel, and the ferrules are made from stainless steel, Aluminum, copper, etc.

Stainless Steel Rope Mesh

◆The Main Parameters of Stainless Steel Cable Mesh

The standard mesh holes of SS cable inter-woven mesh is a diamond shape with 90 degrees top angle. The main parameter's for production are the cable diameter, mesh size(center distance), and the width and length of the mesh panels. For the irregular shape of mesh, we will need a drawing to produce the mesh.

stainless steel cable mesh

The standard mesh holes of SS cable ferrule mesh is a diamond shape with 60 degrees top angle. The main parameter's for production are the cable diameter, long-way and short-way of the mesh opening, and the width and length of the mesh panels. For the irregular shape of mesh, we will need a drawing to produce the mesh.

SS cable ferrule mesh has direction difference in production, the mesh can be installed in vertical or horizontal direction, in the two directions, the means of mesh length and height will be different. It is important to confirm the direction before producing the mesh.

stainless steel ferrule mesh

closed edge rope mesh

SS cable ferrule mesh also has different edge seal options, mainly including the 4 basic types.

But also, we can provide other edge seal options based on those basic options, you can find them in the catalog of our product.

Sealed with standard ferrule

Sealed with eye-ferrule

Sealed by cable loops

Sealed by cable loops with standard ferrule

◆Normal Specifications Of Stainless Steel Cable Mesh

The normal mesh specification is cable diameter 1.2mm-3.2mm and mesh size:20mm-120mm. Apart from the normal specifications, we can customize other specifications of mesh in different cable diameters and mesh sizes.


Item No.s	Cable Diameter		Mesh Opening Size
Item No.s	inch	mm	inch	mm
BZ-3212W	1/8	3.2	4.75 x 4.75	120 x 120
BZ-3210W	1/8	3.2	4 x 4	102 x 102
BZ-3290W	1/8	3.2	3.55 x 3.55	90 x 90
BZ-3276W	1/8	3.2	3 x 3	76 x 76
BZ-3250W	1/8	3.2	2 x 2	51 x 51
BZ-2410W	3/32	2.4	4 x 4	102 x 102
BZ-2490W	3/32	2.4	3.55 x 3.55	90 x 90
BZ-2476W	3/32	2.4	3 x 3	76 x 76
BZ-2460W	3/32	2.4	2.4 x 2.4	60 x 60
BZ-2450W	3/32	2.4	2 x 2	51 x 51
BZ-2076W	5/64	2.0	3 x 3	76 x 76
BZ-2060W	5/64	2.0	2.4 x 2.4	60 x 60
BZ-2050W	5/64	2.0	2 x 2	51 x 51
BZ-2038W	5/64	2.0	1-1/2 x 1-1/2	38 x 38
BZ-1676W	1/16	1.6	3 x 3	76 x 76
BZ-1650W	1/16	1.6	2 x 2	51 x 51
BZ-1638W	1/16	1.6	1-1/2 x 1-1/2	38 x 38
BZ-1630W	1/16	1.6	1.2 x 1.2	30 x 30
BZ-1625W	1/16	1.6	1 x 1	25.4 x 25.4
BZ-1238W	3/64	1.2	1-1/2 x 1-1/2	38 x 38
BZ-1230W	3/64	1.2	1.2 x 1.2	30 x 30
BZ-1225W	3/64	1.2	1 x 1	25.4 x 25.4
BZ-1220W	3/64	1.2	4/5 x 4/5	20 x 20


Item No.s	Cable Diameter		Mesh Opening Size (W×H)
Item No.s	inch	mm	inch	mm
BZ-32120F	1/8	3.2	4.75 x 8.23	120 x 207.8
BZ-32102F	1/8	3.2	4 x 6.9	102 x 176.7
BZ-3290F	1/8	3.2	3.55 x 6.15	90 x 156
BZ-3276F	1/8	3.2	3 x 5.2	76 x 131.6
BZ-3251F	1/8	3.2	2 x 3.46	51 x 88.3
BZ-24102F	3/32	2.4	4 x 6.9	102 x 176.7
BZ-2490F	3/32	2.4	3.55 x 6.15	90 x 156
BZ-2476F	3/32	2.4	3 x 5.2	76 x 131.6
BZ-2460F	3/32	2.4	2.4 x 4.1	60 x 103.9
BZ-2451F	3/32	2.4	2 x 3.46	51 x 88.3
BZ-2076F	5/64	2.0	3 x 5.2	76 x 131.6
BZ-2060F	5/64	2.0	2.4 x 4.1	60 x 103.9
BZ-2051F	5/64	2.0	2 x 3.46	51 x 88.3
BZ-2038F	5/64	2.0	1.5 x 2.6	38 x 65.8
BZ-1676F	1/16	1.6	3 x 5.2	76 x 131.6
BZ-1651F	1/16	1.6	2 x 3.46	51 x 88.3
BZ-1638F	1/16	1.6	1.5 x 2.6	38 x 65.8
BZ-1630F	1/16	1.6	1.2 x 2.08	30 x 51.9
BZ-1625F	1/16	1.6	1 x 1.73	25.4 x 44
BZ-1238F	3/64	1.2	1.5 x 2.6	38 x 65.8
BZ-1230F	3/64	1.2	1.2 x 2.08	30 x 51.9
BZ-1225F	3/64	1.2	1 x 1.73	25.4 x 44
BZ-1220F	3/64	1.2	0.8 x 1.38	20 x 34.6

◆The Applications of Stainless Steel Cable Mesh

The stainless steel rope mesh has a unique decorative style and is more secure. The diamond hole pattern makes the grid strong and flexible. Different opening sizes can be customized to meet the different needs of customers. Widely used in interior staircase decoration, building exterior wall decoration, horizontal or vertical fall protection, dividers, exterior wall cladding, zoos, safety nets, stair railings, suspension bridges, railing fillers, etc.

The applications of ss cable mesh

◆BZ Wire Mesh Technique Supports

design of aviary mesh

Design consultation

BZ Wire Mesh can help our clients on the design stage, we can provide suggestions about the design and installation, offer our clients suitable installation options.

Tools and accessories for installing rope mesh

Accessories and tools

BZ Wire Mesh can provide various of accessories and tools to our clients according to different installation options.

stainless steel cable mesh installation

Installed elements

BZ Wire Mesh can provide the mesh fixed with the frame or other elements as required, this can make the mesh easier to be installed and reduce the installation time.

Construction team of BZWIREMESH

Installation guidance service

BZ Wire Mesh has a professional team to guide the installation on our clients' construction site when it necessary.

◆The Project BZ Wire Mesh Involved

BZ company has finished several important projects in recently years, provide stainless steel cable mesh and service in good quality for our clients, help them to design the options and install the stainless steel cable mesh, and received good reputation from our clients around the world.

Wild animal zoo in Colombia

Wild Animal Zoo in Colombia(13000 ㎡, Woven Type, Bronze Color)

Airport Ceiling system in Mauritius

Airport Ceiling System in Mauritius( 7000 ㎡, Ferrule Type, Supplied With Frame)

Bali zoo in Indonesia

Bali Zoo in Indonesia(850㎡, Woven Type)

Hand rail system in London

Hand Rail System in London(350㎡, Ferrule Type)

Ferrule Type Stainless Steel Cable Mesh

Bird Aviary in Vadaroda India(10200㎡, Ferrule Type)

Climbing Stainless Steel Rope Mesh Installation Site

Science Museum Climbing Net Project in Qingdao(Stainless Steel Cable Mesh, 480㎡, Ferrule Type)

Seaside Sculpture With SS Cable Mesh Elements

Sculpture Work, Material: SS Ferrule Cable Mesh, etc., 120㎡. Cleveland, USA.

Green Wall Mesh made of materials like Stainless Steel Ferrule Cable Mesh, covering 839㎡ in Holland.

Green Wall Mesh, Material: SS Ferrule Cable Mesh, etc., 839㎡. Holland.

Safety Mesh made of materials including Stainless Steel Ferrule Cable Mesh, covering an area of 411㎡ in Holland.

Safety Mesh, Material: SS Ferrule Cable Mesh, etc., 411㎡. Holland.

You may also like:

What Is The Best Railing For Stairs?

How To Install Stainless Steel Cable Mesh？

Things You Want To Know About Stainless Steel Cable Mesh

What Can Stainless Steel Cable Mesh Do For You?

Stainless Steel Wire Mesh

High-Performance Stainless Steel Wire Mesh & Cloth Solutions

● Introduction & Overview

Stainless Steel Wire Mesh (also known as Stainless Steel Wire Cloth or Wire Screen) is precision-manufactured from high-grade stainless steel wires by weaving, welding, or twisting. It offers excellent strength, durability, and superior corrosion resistance, making it ideal for demanding environments in petrochemical, pharmaceutical, food processing, chemical, and architectural applications.

● Main Classifications

We offer the following stainless steel wire mesh series:

- By Weaving Process: Woven (Plain, Twill, Dutch, Five-heddle, Crimped) | Welded | Twisted (Hexagonal)

- By Specification: Heavy-duty | Fine / Micron-level | Ultra-thin | Supplied in rolls or flat panels

SS Wire Mesh Rolls

SS Wire Mesh Panels

- By Opening Shape: Square | Rectangular | Diamond | Hexagonal | Custom shapes (using round, flat, or profiled wires)

Looking to choose the right stainless steel wire mesh for your project? Click on the product categories below to view complete technical specifications, wire diameters & opening sizes, and customization options:

Premium Raw Materials: SS304 vs. SS316

Annealed stainless steel wire on spools, used for weaving stainless steel wire mesh.

BZWIREMESH strictly adheres to ASTM and GB/T standards, utilizing premium alloys to ensure chemical stability:

* SS304 (General Purpose): Offers robust corrosion resistance against alkaline solutions and most organic/inorganic acids. It is ideal for screening and filtration in mining, chemical, and food industries.

* SS316/316L (Superior Grade): Enhanced with molybdenum, 316 mesh provides exceptional resistance to marine environments, aggressive industrial atmospheres, and high temperatures.

* Specialty Materials: We also supply SS430, SS310S, SS321, and other custom alloys upon request.

Technical Specifications & Custom Capabilities

Measuring 40 mesh stainless steel wire mesh density with a mesh counter for quality control.

We offer a comprehensive range of specifications to fit your precise needs:

* Fine Wire Mesh & Heavy Wire Mesh: Stainless steel wire diameter ranges from 0.02 mm to 10 mm, with mesh counts spanning from 1 to 2800.

* Rolls & Sheets: Standard mesh sheets in 1m x 2m or 1.22m x 2.44m; standard rolls in 1m to 1.5m widths.

* Super-Width Mesh: We specialize in super-width cloth, with widths reaching a maximum of 8 meters.

Common Stainless Steel Wire Mesh Specifications
Type	Material	Wire Dia.(mm)	Mesh Count / Opening	Width Max	Typical Use
Plain & Twill Weave	SS 304/316/316L	0.02-2.0	1-800 mesh	8 m	Filtration, Screening, Architecture
Dutch Weave	SS304/316L	0.03x0.018-0.55x0.42	10x64-400x2800	6 m	Fine Filtration (micron level)
Crimped	SS304/316	0.45-10	0.4-100 mm opening	8 m	Heavy-duty, Mining, Protective
Welded	SS304/316	0.4-5.0	1/2" - 4”	3 m	Security, Fencing, Cages
Hexagonal	SS304	0.4-3.0	3/8” - 4”	2 m	Poultry, Gabion, Decoration

Key Features & Industrial Applications

BZ Five-Heddle woven SS wire mesh packing for industrial distillation and filtration.

* Unmatched Durability: High resistance to corrosive chemicals and extreme temperatures.

* Structural Integrity: Engineered to bear heavy loads and resist physical damage.

* Hygiene & Maintenance: Smooth surface finish is easy to clean, perfect for food and medical standards.

* Versatile Usage: Essential for Filtration, Architecture, Industrial Machinery, and Food industries.

Expert Deep-Processed Mesh Products

BZWIREMESH transforms raw wire fabric into high-precision components through cutting, welding, and bending:

* Custom Components: We manufacture mesh discs, tubes, baskets, racks, and specialized filters.

* Applications: Widely utilized in medical disinfection, industrial filtration, and food grilling.

* Quality Finish: All deep-processed products are non-toxic, rust-free, and can be polished or coated.

Ready to Start Your Project?

BZWIREMESH manufactures and supplies a premium range of stainless steel mesh solutions tailored to your technical drawings. [Contact Us Today] – Explore our product details below or send your specific inquiry to our sales team via the email at the page footer.

You may also like:

What Is Stainless Steel Wire Mesh Used For?

The Introduction of Stainless Steel Wire Mesh Filter Accuracy

The Woven Craft and Structure Features of Heavy Duty Stainless Steel Wire Mesh

How to Check the Material of Stainless Steel Wire Mesh?

What Is the Difference Between T-304 and T-316 Stainless Steel Wire Mesh?

Stainless Steel Wire Mesh - An excellent Stainless Steel Mosquito Mesh

Specification Selection of Stainless Steel Wire Mesh Structured Packing

Wire Mesh Fence

Metal wire mesh fence are a series of products used for isolation and protection, metal wire mesh fence has the advantages of low price, easy for installation good strength, beautiful appearance and long service life, it is widely used in the enclosure and protection of gardens, buildings, traffic facilities, factories, warehouses, stadiums, airports and other areas, as well as protection and isolation of farms, pastures, orchards and other large-scale sites.

Wire mesh fence is made in a similar way to woven fabric. Wires are woven together to form wire meshes in different patterns. Welding wire mesh simply lays the vertical wire on top of the horizontal wire and uses a welding process that fuses the two wires together. Materials used to make wire mesh fence include carbon steel, galvanized steel, aluminum mesh, and stainless steel. Heavier wire mesh fences must be pre-crimped. After the crimping process, the material is still very durable and strong.

BZWIREMESH produce and sales various of metal wire mesh fence products, it is mainly including Welded Wire Mesh Fence, Anti-Climb Wire Mesh Fence, Chain-link Wire Mesh Fence, Expanded Metal Mesh Fence, Picket Fencing, Razor Barbed Tape& Razor Barbed Fence.

Welded Wire Mesh Fence, also called welded wire mesh guardrail or welded wire guardrail, is a commonly used guardrail product. Welded mesh fence board has the advantages of good strength, beautiful appearance, low cost and convenient installation.

Anti-climbing Wire Mesh Fence is also known as 358 high security fence. It is a special wire mesh fence product with very high safety. Thick wire and small opening size can prevent cutting pliers from entering.

Chain Link Wire Mesh Fence have a flexible surface that absorbs impact and keeps people safe, making them ideal for use in stadiums, outdoor basketball courts, baseball fields, golf courses, and other facilities that require extremely high wire.

Hexagonal Wire Mesh Fence has low cost and good preventive effect, and it is easy to install. For detailed information and product suggestions, welcome to contact us!
